Miniature A/C Water Condensate Drain Pumps


Mini-Flowatch 2 Pump

S05LC2

Specifications
Fitted for air conditioners up to 10 KW maximum.
220 Volts / 50 Hz / 19 Watts.
Pump unit dimensions: 85 x 28 x 48 mm only !
Level sensor dimensions: 78 x 38 x 37 mm.
Wiring designed to ease maintenance.
2 possible ways out from the level sensor for the flow (the unused one must be capped with the black cap).

Features
Quietest (21dB)
4,500hr ave. life
Safe plug and socket leads
Easy to connect/disconnect, (replace)
IP64 watertight (safest in the market)
Now in sandy yellow colour
Duct Kit with duct version available.

Package
Delivered with its full set of accessories, helps saving time and energy:

  • Diameter converter 4mm / 6 mm
  • Strong double-sided adhesive
  • 2 m long tube.
  • Curved pipe to reach the air conditioner’s tank
  • Quickly readable instructions for use + drawings, easing set-up and maintenance



Mini-Flowatch 2 Pump and Duct Kit

S05LC2D

Specifications
Fitted for air conditioners up to 10 KW maximum.
220 Volts / 50 Hz / 19 Watts.
Pump unit dimensions: 85 x 28 x 48 mm only !
Level sensor dimensions: 78 x 38 x 37 mm.
Wiring designed to ease maintenance.
2 possible ways out from the level sensor for the flow (the unused one must be capped with the black cap).

Features
Quietest (21dB)
4,500hr ave. life
Safe plug and socket leads
Easy to connect/disconnect, (replace)
IP64 watertight (safest in the market)
Now in sandy yellow colour

Package
Delivered with its full set of accessories, helps saving time and energy:

  • Diameter converter 4mm / 6 mm
  • Strong double-sided adhesive
  • 2 m long tube
  • Curved pipe to reach the air conditioner’s tank
  • Quickly readable instructions for use + drawings, easing set-up and maintenance
  • 800 x 70mm long plastic duct
  • Jig for fixing holes localization
  • IP 64 error-proof connectors with 2 meters cable, protection against dust and water spilling
